PCX-160R Pump
Chemical transfer pump with head up to 49 mtr and for 2880 RPM motor.
  • Standard quality pump supplied with Teflon bellow mechanical seal and ceramic sleeve.
  • Model PCX-40 is high head and low capacity pump with 2880 RPM motor is excellent for vaccum ejector.
These pumps can be used by various industries for application as under:
  • Efficient for scrubbing corrosive and aggressive gases like Br2, Co3, Cl2, So2, So3, and L2 etc.
  • Used in continuous process in acid pickling liner in steel industries.
  • Used for re-circulation of chemicals in electroplating plants.
  • Used by dyes and intermediate industries for use against filter press due to high pressure.
Sealing Options:
  • Externally Mounted Mechanical Seal
  • Gland Packing
Performance Data:
Model Suction
H.P. RPM Head in Mtr. / Cap. in M3 / hr.
PCX 160R 40 40 150 3 2900 24 22 20 18 15 10
00 03 05 10 20 26

NOTE: Performance Applicable to Liquid of Specific Gravity 1 and Viscosity as of Water.
