PCX-55 Pump

Chemical Transfer Pump With Head up to 18 Mtr and for 1440 RPM Motors.

These pumps can be used by various industries for application as under :-
  • Used for transferring acids, alkalies etc.
  • Also used for loading and unloading of acids, alkalies road tanker.
  • Used for re-circulation of chemicals in electroplating and water treatment plants.
  • Used for effluent treatment plants for negative suction with foot valves or with priming chamber.
Sealing Options:
  • Externally Mounted Mechanical Seal
  • Gland Packing
Performance Data:
Model Suction
mm
Delivery
mm
Imp.Dia.
mm
H.P. RPM Head in Mtr. / Cap. in M3 / hr.
PCX 55 75 50 210 5 1440 18 17 15 14 12 10
00 06 10 20 28 37


NOTE: Performance Applicable to Liquid of Specific Gravity 1 and Viscosity as of Water.
