PCX-170 Pump |
Chemical transfer pump with head up to 49 mtr and for 2880 RPM motor.
- Standard quality pump supplied with Teflon bellow mechanical seal and ceramic sleeve.
- Model PCX-40 is high head and low capacity pump with 2880 RPM motor is excellent for vaccum ejector.
|
|
|
|
These pumps can be used by various industries for application as under: |
- Efficient for scrubbing corrosive and aggressive gases like Br2, Co3, Cl2, So2, So3, and L2 etc.
- Used in continuous process in acid pickling liner in steel industries.
- Used for re-circulation of chemicals in electroplating plants.
- Used by dyes and intermediate industries for use against filter press due to high pressure.
|
Sealing Options: |
- Externally Mounted Mechanical Seal
- Gland Packing
|
Performance Data: |
Model |
Suction
mm |
Delivery
mm |
Imp.Dia.
mm |
H.P. |
RPM |
Head in Mtr. / Cap. in M3 / hr. |
PCX ™ 170 |
75 |
50 |
160 |
7.5 |
2900 |
35 |
32 |
30 |
25 |
20 |
12 |
00 |
15 |
25 |
32 |
38 |
50 |
|
|
NOTE: Performance Applicable to Liquid of Specific Gravity 1 and Viscosity as of Water. |
|
|
