| PCXL 50 Pump |
These pumps can be used by various industries for application as under :
- Ideal for bulk transfer of acidic effluents for big process plants.
- Scrubbing acidic fumes in steel industries.
- Moulded polypropylene series is specially designed for high capacity and high head application.
- Suitable for continuous service.
|
|
 |
|
- Ideal for circulation of chemical in metal finishing industries.
- Handling liquids in various industries like cellulose, sugar, textile, food etc…
- Self venting type casing
|
| Sealing Options: |
- Externally Mounted Mechanical Seal
- Gland Packing
|
| Performance Data: |
| Model |
Suction
mm |
Delivery
mm |
Imp.Dia.
mm |
H.P. |
RPM |
Head in Mtr. / Cap. in M3 / hr. |
| PCXL- 50 |
50 |
50 |
210 |
15 |
2900 |
64 |
60 |
58 |
55 |
50 |
45 |
| 00 |
20 |
35 |
45 |
52 |
60 |
|
| |
NOTE: Performance Applicable to Liquid of Specific Gravity 1 and Viscosity as of Water. |
| |
| |
