PCX-50R Pump |
Chemical Transfer Pump With Head up to 18 Mtr and for 1440 RPM Motors. |
These pumps can be used by various industries for application as under :-
- Used for transferring acids, alkalies etc.
- Also used for loading and unloading of acids, alkalies road tanker.
- Used for re-circulation of chemicals in electroplating and water treatment plants.
- Used for effluent treatment plants for negative suction with foot valves or with priming chamber.
|
|
|
|
Sealing Options: |
- Externally Mounted Mechanical Seal
- Gland Packing
|
Performance Data: |
Model |
Suction
mm |
Delivery
mm |
Imp.Dia.
mm |
H.P. |
RPM |
Head in Mtr. / Cap. in M3 / hr. |
PCX ™50R |
40 |
40 |
205 |
2 |
1440 |
12 |
11 |
10 |
08 |
05 |
00 |
02 |
06 |
12 |
25 |
|
|
NOTE: Performance Applicable to Liquid of Specific Gravity 1 and Viscosity as of Water. |
|
|
